Note: MD17400 $MN_OEM_GLOBAL_INFO[0] is used with functions such as logbook,
licensing, etc. to store the machine identity.
17515 TOOL_RESETMON_MASK N09 -
- Tool data behavior with RESETMON DWORD PowerOn
-
808d-me42 - 0x14 0 0x49F 0/0 S
808d-me62 - 0x14 0 0x49F 0/0 S
808d-te42 - 0x14 0 0x49F 0/0 S
808d-te62 - 0x14 0 0x49F 0/0 S
808d-mte40 - 0x14 0 0x49F 7/2 M
808d-mte60 - 0x14 0 0x49F 7/2 M
Description: The 5th parameter of the RESETMON command defines which tool status is to be reset. If
the 5th parameter is omitted, it is replaced by the value in this MD. With the PI
service "_N_TRESMON", work is always done with this value.
In that case, the bits are always assigned as the bits in the tool status $TC_TP8[x].
Bit no.: 0 Bit value: 0 hex value: -
Meaning: Tool status "active" remains unchanged
Bit no.: 0 Bit value: 1 hex value: 'H1'
Meaning: Tool status "active" is deleted
Bit no.: 1 Bit value: 0 hex value: -
Meaning: Tool status "released" remains unchanged
Bit no.: 1 Bit value: 1 hex value: 'H2'
Meaning: Tool status "released" is set
Bit no.: 2 Bit value: 0 hex value: -
Meaning: Tool status "locked" remains unchanged
Bit no.: 2 Bit value: 1 hex value: 'H4'
Meaning: Tool status "locked" is deleted, if this is permitted by the monitoring data
and the 4th parameter is set correspondingly.
Bit no.: 3 Bit value: 0 hex value: -
Meaning: Tool status "measure" remains unchanged
Bit no.: 3 Bit value: 1 hex value: 'H8'
Meaning: Tool status "measure" is set.
Bit no.: 4 Bit value: 0 hex value: -
Meaning: Tool status "prewarning limit" remains unchanged
Bit no.: 4 Bit value: 1 hex value: 'H10'
Meaning: Tool status "prewarning limit" is deleted, if this is permitted by the
monitoring data and the 4th parameter is set.
Bit no.: 5 Not permitted (tool status "tool is being changed")
Bit no.: 6 Not permitted (tool status "tool is fixed-location-coded")
Bit no.: 7 Bit value: 0 hex value: -
Meaning: Tool status "was in use" remains unchanged
Bit no.: 7 Bit value: 1 hex value: 'H80'
Meaning: Tool status "was in use" is deleted
Bit no.: 8 Bit value: 0 Not permitted (tool status "is in retract")
Bit no.: 9 Bit value: 0 hex value: -
Meaning: Tool status "locked is ignored" remains unchanged
Bit no.: 9 Bit value: 1 hex value: 'H200'
Meaning: Tool status "locked is ignored" is deleted
Bit no.: 10 Bit value: 0 hex value: -
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 87
