Parameter: dM/dt Rise Active - dM/dt Rise (/Filter Time) - dM/dt Rise Hysteresis - Filter Time
•
Default setting (_:9871:103) dM/dt rise active = no
•
Default setting (_:9871:107) dM/dt rise (/Filter time) = 0.300 A
•
Default setting (_:9871:115) dM/dt rise hysteresis = 0.980 p.u.
•
Default setting (_:9871:112) Filter time = 2 periods
With the dM/dt rise active parameter, you activate the gradient trigger in order to monitor the positive
gradients of the current in the negative-sequence system using the set filtering time (input in periods).
Parameter Value Description
yes
The positive gradient of the current in the negative-sequence system is
monitored.
no
The positive gradient of the current in the negative-sequence system is not
monitored.
The hysteresis is preset at the factory to 0.980 p.u. (equal to 2 %) of the parameter dM/dt rise (/Filter
time) and can be adjusted.
Settings
Addr. Parameter C Setting Options Default Setting
General
_:9751:1 Trig. I fund 1:Mode
•
off
•
on
•
test
off
_:9751:117 Trig. I fund 1:Phase-
selective
•
no
•
yes
no
_:9751:112 Trig. I fund 1:Filter time 2 cycles to 250 cycles 2 cycles
Max. trigger
_:9751:101 Trig. I fund 1:Max. active
•
no
•
yes
yes
_:9751:105 Trig. I fund 1:Max. (Non-
phs sel.)
1 A @ 100 Irated 0.030 A to 100.000 A 1.200 A
5 A @ 100 Irated 0.15 A to 500.00 A 6.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 1.200 A
5 A @ 50 Irated 0.15 A to 250.00 A 6.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 1.200 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 6.000 A
_:9751:118 Trig. I fund 1:Max. phs A 1 A @ 100 Irated 0.030 A to 100.000 A 1.200 A
5 A @ 100 Irated 0.15 A to 500.00 A 6.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 1.200 A
5 A @ 50 Irated 0.15 A to 250.00 A 6.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 1.200 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 6.000 A
_:9751:119 Trig. I fund 1:Max. phs B 1 A @ 100 Irated 0.030 A to 100.000 A 1.200 A
5 A @ 100 Irated 0.15 A to 500.00 A 6.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 1.200 A
5 A @ 50 Irated 0.15 A to 250.00 A 6.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 1.200 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 6.000 A
7.5.2.9
Fault Recorder
7.5 Trigger Functions 3-Phase
SIPROTEC 5, Fault Recorder, Manual 323
C53000-G5040-C018-5, Edition 11.2017
