Additional cause Meaning
Command cancellation Command cancellation
Monitoring time expired Monitoring time expired
Object not selected Object not selected
No access right. No access right
Final position exceeded Final position exceeded
Target value not attained Target value not attained
Loss of connection Loss of connection
unknown unknown
Object already selected Object already selected
inconsistent parameter(s) inconsistent parameter(s)
blocked by foreign access blocked by foreign access
Select time-out Select time-out
Communication is interrupted Communication is interrupted
Fault occurred Fault occurred
Logs
General
Indications are saved in logs inside the device and are available for later analyses. Different logs allow catego-
rization of indication logging based on operating states (e.g. operational and fault logs) and based on fields of
application.
Table 3-2
Log Overview
Log Logging
Operational log Operational indications
Setting-history log Parameter changes
User-defined log User-defined indication scope
Security log Access with safety relevance
Device-diagnosis log Error of the device (software, hardware) and the connection circuits
Communication Log Status of communication interfaces
Administering Logs
Logs have a ring structure and are automatically managed. If the maximum capacity of a log is exhausted, the
oldest entries disappear before the newest entries. During a supply voltage failure, recorded data are securely
held by means of battery buffering or storage in the flash memory. You can read and analyze the log from the
device with DIGSI 5. The device display and the navigation allow you to read and analyze the logs on site using
keys.
Configurability of the Logs
The indication capacity that may be recorded in configurable logs (for example, ground-fault log) is laid down
in columns of the information routing (matrix) of DIGSI 5 specifically defined for this purpose.
Procedure
•
To reach the information routing of your SIPROTEC 5 device, use the project tree window. Access is only
through the project:
Project → Device → Information Routing
•
Select the associated routing column in the matrix from:
Target → Logs → Frequency Trigger Column
3.1.5
3.1.5.1
System Functions
3.1 Indications
46 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
