Addr. Parameter C Setting Options Default Setting
_:15271:102 General:Tol. trend
voltage
0.100 % to 5.000 % 2.000 %
Information List
Frequency
No. Information Data Class
(Type)
Type
Routing f
_:301 Routing f:f MV O
Voltage
No. Information Data Class
(Type)
Type
Routing I
_:300 Routing V:Vph rms WYE O
_:301 Routing V:Vpp rms DEL O
_:302 Routing V:VN rms MV O
_:303 Routing V:Vph fd. WYE O
_:304 Routing V:Vpp fd. DEL O
_:305 Routing V:VN fd. CMV O
_:306 Routing V:V0 CMV O
_:307 Routing V:V1 CMV O
_:308 Routing V:V2 CMV O
PQ 10/12 Cycles
No.
Information Data Class
(Type)
Type
PQ 10/12cyc
_:300 PQ 10/12cyc:f MV O
_:301 PQ 10/12cyc:Vph rms WYE O
_:302 PQ 10/12cyc:Vpp rms DEL O
_:303 PQ 10/12cyc:VN rms MV O
_:304 PQ 10/12cyc:u0 MV O
_:305 PQ 10/12cyc:u2 MV O
PQ Trend
No.
Information Data Class
(Type)
Type
PQ trend
_:300 PQ trend:f MV O
_:301 PQ trend:Vph rms WYE O
_:302 PQ trend:Vpp rms DEL O
7.6.2.6
Fault Recorder
7.6 Measurands and Recorder Routing Functions
SIPROTEC 5, Fault Recorder, Manual 355
C53000-G5040-C018-5, Edition 11.2017
