Typographic and Symbol Conventions
The following typefaces are used to characterize parameters in the text:
Mode
Parameter name
_:661:1
Parameter address
_ stands for the address combination from function
group:function
661, for example, stands for the address of the
setting parameter
from
Parameter state
The following symbols are used in drawings:
Icon Description
Parameter
Parameters with setting values
The default setting is in the 1st position and displayed
in italics
Parameters with application-dependent setting values
Dynamic settings:
State logic
Health of a function, stage, or function block
External binary input signal with indication number
External output signal with indication number and
additional information
External output signal without indication number
Measured output value
A.2
Appendix
A.2 Typographic and Symbol Conventions
SIPROTEC 5, Fault Recorder, Manual 455
C53000-G5040-C018-5, Edition 11.2017
