The phase rotation is important for protection functions which process phase, loop, and directional informa-
tion. You can set the phase sequence with the Phase sequence parameter in the function block General of
the power-system data (see chapter 5 Power-System Data).
To supervise the phase rotation, the device compares the measured phase sequence with the set phase
sequence. For abnormal phase sequences, the indication Failure is generated.
The connection of the voltages to the device does not depend on the selected phase sequence. The connec-
tion diagrams are shown in chapter A Appendix.
Release Condition
The supervision of the voltage phase rotation is carried out when all measured phase-to-phase voltages are
greater than 40 V.
Blocking of the Function
The following blockings reset the function completely:
•
Via the binary input signal
>Block function from an external or internal source
•
Via a protection pickup
The pickup signal from a protection function blocks the indication Failure .
Delay failure indication
When the device detects an inverted phase-rotation direction for the duration of the Delay failure indi-
cation, the indication
Failure is generated.
Application and Setting Notes
Parameter: Delay failure indication
•
Recommended setting value (_:6) Delay failure indication = 5.00 s
Set the Delay failure indication parameter so that overfunctions due to disturbing influences (such as
switching operations) are avoided. Siemens recommends using the default setting.
Settings
Addr.
Parameter C Setting Options Default Setting
Supv. ph.seq.V
_:1 Supv. ph.seq.V:Mode
•
off
•
on
•
test
off
_:6 Supv. ph.seq.V:Delay
failure indication
0.00 s to 100.00 s 5.00 s
Information List
No.
Information Data Class
(Type)
Type
Supv. ph.seq.V
_:82 Supv. ph.seq.V:>Block function SPS I
_:54 Supv. ph.seq.V:Inactive SPS O
_:52 Supv. ph.seq.V:Behavior ENS O
_:53 Supv. ph.seq.V:Health ENS O
_:71 Supv. ph.seq.V:Failure SPS O
8.3.4.4
8.3.4.5
8.3.4.6
Supervision Functions
8.3 Supervision of the Secondary System
SIPROTEC 5, Fault Recorder, Manual 379
C53000-G5040-C018-5, Edition 11.2017
