Indication Type Group
Warning
Explanation
Power-system data:meas. point I-3ph:superv.
Phsseq.I:
(_:71) Failure
SPS CFC
Failure of the current phase-rotation
supervision (see chap. 8.3.8.1 Overview
of Functions )
Power-system data:meas. point I-3ph:superv.
Sum I
(_:71) Failure
SPS CFC
Failure of the current sum (see chap.
8.3.7.1 Overview of Functions )
Power-system data:meas. point
I-3ph:superv.ADC sum.I:
(_:71) Failure
SPS CFC
Failure of the quick current sum (see
chap. 8.4.2.1 Overview of Functions)
The failure indication indicates a fault in
the analog-digital converter at the
power input.
•
Check the exterior wiring.
•
If the fault is not remedied, contact
the Customer Support Center.
Quality: The internally managed current
measured values are marked with the
invalid quality attribute.
Blocking: The protection functions
based on current measurement are
blocked.
Power-system data:meas. point V-3ph:
Volt.Trans.Cir.B:
(_:500) >Open
SPS CFC
Voltage-transformer circuit breaker is
open.
Blocking: Appropriate functions are
either blocked definitely or the blocking
can be set individually.
Power-system data:meas. point V-3ph:
Superv. bal. V:
(_:71) Failure
SPS CFC
Failure of the voltage balance (see chap.
8.3.2.1 Overview of Functions )
Power-system data:meas. point V-3ph:
Superv. Phsseq.V:
(_:71) Failure
SPS CFC
Failure of the voltage phase-rotation
supervision (see chap. 8.3.4.1 Overview
of Functions )
Power-system data:meas. point V-3ph:
Superv. of Sum V:
(_:71) Failure
SPS CFC
Failure of the voltage sum (see chap.
8.3.3.1 Overview of Functions )
Defect Severity 2
Faults of defect severity 2 are fatal device faults that lead to an immediate restart of the device (reset).
This occurs when the device data is corrupted (for example, RAM memory), if a restart prevents restoration of
data consistency. The device goes briefly out of operation, a failure is avoided.
Life contact
Is terminated during the restart
Red error LED Is activated during the restart
i
i
NOTE
If the fault of defect severity 2 has not be been removed after 3 unsuccessful restarts (reset), the fault is
automatically assigned to defect severity 3. The device will automatically turn to the fallback mode.
8.8.3
Supervision Functions
8.8 Error Responses and Corrective Measures
SIPROTEC 5, Fault Recorder, Manual 405
C53000-G5040-C018-5, Edition 11.2017
