The procedure is described in chapter 7.1.2 Step 1: Creating a New Project and Adding a New Device and in
the DIGSI Help.
Parameter: Tol. trend frequency
•
Default setting (_:15241:101) Tol. trend frequency = 0.200 %
Using the parameter Tol. trend frequency, you set the tolerance range for the frequency measured
value at which a new RMS value is recorded following an exceedance.
The setting value refers to the rated frequency set as a parameter.
Parameter: Tol. trend voltage
•
Default setting (_:15241:102) Tol. trend voltage = 2.000 %
Using the parameter Tol. trend voltage, you set the tolerance range for the voltage measured value at
which a new RMS value is recorded following an exceedance.
The setting value refers to the rated voltage set as a parameter.
Settings
Addr. Parameter C Setting Options Default Setting
General
_:15241:101 General:Tol. trend
frequency
0.010 % to 1.000 % 0.200 %
_:15241:102 General:Tol. trend
voltage
0.100 % to 5.000 % 2.000 %
Information List
Frequency
No.
Information Data Class
(Type)
Type
Routing f
_:301 Routing f:f MV O
Current
No.
Information Data Class
(Type)
Type
Routing I
_:300 Routing I:Iph rms WYE O
_:301 Routing I:IN rms MV O
_:302 Routing I:Iph fd. WYE O
_:303 Routing I:IN fd. CMV O
_:304 Routing I:I0 CMV O
_:305 Routing I:I1 CMV O
_:306 Routing I:I2 CMV O
Voltage
No.
Information Data Class
(Type)
Type
Routing I
_:300 Routing V:Vph rms WYE O
_:301 Routing V:Vpp rms DEL O
7.6.4.4
7.6.4.5
Fault Recorder
7.6 Measurands and Recorder Routing Functions
358 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
