Suzuki RMX450Z Service Manual

Front Suspension: 2B-16
Tightening Torque Specifications
BA02J22207002
NOTE
The specified tightening torque is described in the following.
“Front Fork Components” (Page 2B-1)
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List” in Section 0C
(Page 0C-8).
Special Tools and Equipment
Recommended Service Material
BA02J22208001
NOTE
Required service material is also described in the following.
“Front Fork Components” (Page 2B-1)
Fastening part
Tightening torque
Note
N⋅mkgf-mlbf-ft
Fork lower clamp bolt 23 2.3 16.5 )(Page 2B-3)
Fork upper clamp bolt 23 2.3 16.5 )(Page 2B-3)
Front fork cap bolt 34 3.4 24.5 )(Page 2B-3)
Fork protector bolt 4.9 0.49 3.5 )(Page 2B-3)
Compression damper unit 30 3.0 21.5 )(Page 2B-8)
Lock-nut/center bolt 22 2.2 16.0 )(Page 2B-10)
Center bolt 69 6.9 50.0 )(Page 2B-10)
Fork cap bolt 34 3.4 24.5 )(Page 2B-11)
Air bleeder valve 1.3 0.13 1.0 )(Page 2B-13)
Air bleeder valve 1.3 0.13 1.0 )(Page 2B-14)
Material SUZUKI recommended product or Specification Note
Fork Oil FORK OIL SS-19 or equivalent — )(Page 2B-7) / )(Page 2B-
8) / )(Page 2B-8) /
)(Page 2B-9) / )(Page 2B-
10) / )(Page 2B-11) /
)(Page 2B-13) /
)(Page 2B-13) /
)(Page 2B-14) /
)(Page 2B-15)

Suzuki RMX450Z Specifications

General

Displacement	449cc
Compression Ratio	12.5:1
Fuel System	Fuel injection
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Engine Type	4-stroke, liquid-cooled, DOHC
Bore x Stroke	96.0 mm x 62.1 mm
Front Brakes	Single disc
Rear Brakes	Single disc
Front Tire	80/100-21
Fuel Tank Capacity	6.2 L (1.6 US gal)
Overall Length	2185 mm (86.0 in)
Ground Clearance	325mm
Seat Height	955mm
Wheelbase	1, 480mm
