ENGINE AND EMISSION CONTROL SYSTEM (TBI FOR G10) 6E1-1
GENERAL DESCRIPTION 6E1- 2. . . . . . . . . . . . . .
AIR AND FUEL DELIVERY SYSTEM 6E1- 4. . . . .
ELECTRONIC CONTROL SYSTEM 6E1- 5. . . . . .
ON-VEHICLE SERVICE 6E1- 8. . . . . . . . . . . . . . . .
General 6E1- 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accelerator Cable Adjustment 6E1- 8. . . . . . . . . .
Idle Speed Inspection 6E1- 8. . . . . . . . . . . . . . . . .
AIR AND FUEL DELIVERY SYSTEM 6E1- 9. . . . .
Fuel Pressure 6E1- 9. . . . . . . . . . . . . . . . . . . . . . . .
Fuel Pump 6E1-11. . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle Body 6E1-12. . . . . . . . . . . . . . . . . . . . . . . .
Fuel injector 6E1-15. . . . . . . . . . . . . . . . . . . . . . . . .
ELECTRONIC CONTROL SYSTEM 6E1-17. . . . . .
ECM 6E1-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAP Sensor 6E1-18. . . . . . . . . . . . . . . . . . . . . . . . .
TP Sensor 6E1-19. . . . . . . . . . . . . . . . . . . . . . . . . . .
IAT Sensor 6E1-20. . . . . . . . . . . . . . . . . . . . . . . . . .
ECT Sensor 6E1-21. . . . . . . . . . . . . . . . . . . . . . . . .
Heated Oxygen Sensor -1 and -2 6E1-23. . . . . . .
Vehicle Speed Sensor 6E1-24. . . . . . . . . . . . . . . . .
Fuel Level Sensor (Gauge) 6E1-24. . . . . . . . . . . .
Crankshaft Position Sensor 6E1-25. . . . . . . . . . . .
Main Relay 6E1-25. . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Pump Relay 6E1-26. . . . . . . . . . . . . . . . . . . . .
Fuel Injector Resistor 6E1-26. . . . . . . . . . . . . . . . .
Fuel Cut Operation 6E1-26. . . . . . . . . . . . . . . . . . .
ISC System 6E1-26. . . . . . . . . . . . . . . . . . . . . . . . . .
ISC Actuator 6E1-27. . . . . . . . . . . . . . . . . . . . . . . . .
CTP Switch 6E1-28. . . . . . . . . . . . . . . . . . . . . . . . . .
ISC Actuator Relay 6E1-29. . . . . . . . . . . . . . . . . . .
EFE Heater Control System 6E1-29. . . . . . . . . . . .
EFE Heater 6E1-29. . . . . . . . . . . . . . . . . . . . . . . . . .
EFE Heater Relay 6E1-30. . . . . . . . . . . . . . . . . . . .
Radiator Fan Control System 6E1-30. . . . . . . . . .
Radiator Fan Control Relay 6E1-31. . . . . . . . . . . .
Radiator Fan 6E1-31. . . . . . . . . . . . . . . . . . . . . . . . .
EMISSION CONTROL SYSTEM 6E1-32. . . . . . . . .
EVAP Control System 6E1-32. . . . . . . . . . . . . . . . .
PCV System 6E1-34. . . . . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOLS 6E1-36. . . . . . . . . . . . . . . . . . . . . .
TIGHTENING TORQUE
SPECIFICATIONS 6E1-36. . . . . . . . . . . . . . . . . . . .
SECTION 6E1
ENGINE AND EMISSION CONTROL SYSTEM
(TBI FOR G10)
WARNING:
For vehicles equipped with a Supplemental Inflatable Restraint Air Bag System:
D Service on or around Air Bag System Components or Wiring must be performed only by an authorized
Suzuki dealer. Please observe all WARNINGS and SERVICE PRECAUTIONS in Section 9J under “On-
Vehicle Service” and the Air Bag System Component and Wiring Location view in Section 9J before
performing service on or around Air Bag System Components or Wiring. Failure to follow WARNINGS
could result in unintended air bag deployment or could render the air bag inoperative. Either of these
two conditions may result in severe injury.
D SDM can maintain sufficient voltage to cause a deployment of air bags for up to 15 seconds after igni-
tion switch is turned to “LOCK” position, battery is disconnected or fuse powering SDM is removed.
Work must be started after 15 seconds from the time.
NOTE:
For the descriptions for vehicle without warm up three way catalytic converter (WU TWC), refer to the same
section of the Service Manual mentioned in the FOREWORD of this manual.
