→ Technical product information
→ Vehicle electrics
→ Function
→ Passenger protection
→ Deactivation of airbag units
→ Systems
4.7 Renewing airbag units following an ac‐
cident
4.7.1 Accident involving triggering of airbag
Following the renewal of airbag units or the airbag control unit,
the labels (only tear-off strips) of the new components must be
stuck onto the “Registry note 2 for Airbag Systems”. For registra‐
tion, the “Registry note 2 for Airbag Systems” must be sent on to
the responsible distribution centre or importer.
The “Registry note 2 for Airbag Systems” can be printed out of
the “Technical Service Handbook”:
ElsaWin
→ Technical Service Handbook
→ Technical product information
→ Vehicle electrics
→ Function
→ Passenger protection
→ Deactivation of airbag units
→ Systems
In the “Technical service handbook”, the “Process ID” or the “TPI
number” for this procedure is “2000987”.
As a matter of rule, the following components will have to be re‐
newed following an accident where the airbag has been triggered:
♦ All triggered airbag units.
♦ Supports and retainer for front passenger module if front pas‐
senger airbag was triggered.
♦ Coil connector with slip ring, when driver airbag has triggered.
♦ All seat belts with triggered belt tensioners.
♦ In addition, the following must also be replaced if necessary
(visual check): all damaged components.
4.7.2 Accident not involving triggering of air‐
bag
♦ If the airbag warning lamp (K 75) does not indicate a fault, it is
not necessary to replace the airbag components. The seat
belts should be checked separately.
Golf 2004 ➤ , Golf 2009 ➤
General body repairs, interior - Edition 05.2010
4. Airbag 117
