7 Luggage compartment trims
7.1 Removing and installing luggage com‐
partment cover side cover
Note
Removal and installation is described for the right vehicle side.
Follow same instructions for the left side as appropriate.
7.1.1 Removing
– Switch off ignition.
2-door
– Remove upper B-pillar trim. Front seat belt anchor rail need
not be removed ⇒ page 228 .
– Remove bench seat ⇒ page 304 .
– Remove backrest ⇒ page 305 .
– Remove side panel trim ⇒ page 233 .
4-door, vehicles ▸06/2005
– Remove bench seat ⇒ page 304 .
– Remove side padding (4-door):
♦ with rear side airbags ⇒ page 306
♦ with no rear side airbags ⇒ page 307
– Remove wheel housing liner (4-door) ⇒ page 84 .
4-door, vehicles with rear side airbag, 06/2005▸
– Remove side padding (4-door):
♦ with rear side airbags ⇒ page 306
– Remove wheel housing liner (4-door) ⇒ page 84 .
4-door, vehicles without rear side airbag, 06/2005▸
– Remove wheel housing trim, 4-door, without rear side airbag
⇒ page 85 .
All vehicles
– Pull lock carrier cover out of mountings in transition area to
support.
– Remove bolts -1- and -2- (1.5 Nm).
– Pull support -3- out of mountings.
– Depending on vehicle equipment, disconnect wiring harness
from support.
Golf 2004 ➤ , Golf 2009 ➤
General body repairs, interior - Edition 05.2010
7. Luggage compartment trims 241
