– Remove dash panel centre vent.
♦ Vehicles with no Climatronic ⇒ page 48
♦ Vehicles with Climatronic ⇒ page 50
– Remove dash panel centre trim ⇒ page 58 .
Golf 2009 ▸
– Remove dash panel central trim (Golf 2009 ▸) ⇒ page 59
– Remove air conditioner controls unit / heater controls unit trim
(Golf 2009 ▸) ⇒ page 59
– Remove centre cover (Golf 2009 ▸) ⇒ page 68
– Remove centre console:
♦ Basic (Golf 2009 ▸) ⇒ page 10
♦ Highline (Golf 2009 ▸) ⇒ page 24
All vehicles
– Remove glove compartment ⇒ page 69 .
Vehicles with radio system
– Remove radio ⇒ Communication; Rep. Gr. 91 ; Removing
and installing radio unit and radio navigation system .
Golf 2009 ▸
– Remove storage compartment in centre of dash panel (Golf
2009 ▸) ⇒ page 53
All vehicles
Vehicles with navigation
– Remove display and controls unit for navigation system ⇒
Communication; Rep. Gr. 91 ; Removing and installing radio
and radio navigation system .
Vehicles with Climatic or Climatronic
– Remove controls for Climatic or Climatronic ⇒ Heating, air
conditioning system; Rep. Gr. 87 .
– Vehicles with Climatic, disconnect connector on centre vent
temperature sender -G191- or on vehicles with Climatronic,
disconnect left vent temperature sender -G150- and right vent
temperature sender -G151- ⇒ Heater, air conditioning system;
Rep. Gr. 87
Vehicles with heating
– Remove heater controls ⇒ Heater, air conditioning system;
Rep. Gr. 80 ; Repairing heater; Removing and installing reg‐
ulation for hot air and fresh air .
Golf 2009 ▸
– Remove vent in middle of dash panel (Golf 2009 ▸)
⇒ page 56
All vehicles
– Remove steering column trim ⇒ page 61 .
– Remove steering column electronics control unit -J527- ⇒
Electrical system; Rep. Gr. 94 ; Steering column switch; Re‐
moving and installing steering column electronics control unit
-J527- .
– Remove airbag coil connector and return ring with slip ring -
F138- ⇒ Electrical system; Rep. Gr. 94 ; Steering column
Golf 2004 ➤ , Golf 2009 ➤
General body repairs, interior - Edition 05.2010
184 Rep. Gr.70 - Trim, insulation
