4.7 Removing and installing C-pillar trim
Note
Removal and installation is described for the left vehicle side.
Follow same instructions for the right side as appropriate.
4.7.1 Removing
– Switch off ignition.
4-door, vehicles ▸06/2005
– Remove bench seat ⇒ page 304 .
– Remove side padding (4-door):
♦ with rear side airbags ⇒ page 306
♦ with no rear side airbags ⇒ page 307
– Remove wheel housing liner (4-door) ⇒ page 84 .
4-door, vehicles with rear side airbag, 06/2005▸
– Remove side padding (4-door):
♦ with rear side airbags ⇒ page 306
– Remove wheel housing liner (4-door) ⇒ page 84 .
4-door, vehicles without rear side airbag, 06/2005▸
– Remove wheel housing trim, 4-door, without rear side airbag
⇒ page 85 .
2-door
– Remove upper B-pillar trim. Belt end anchor or anchor rail for
front seat belt need not be removed ⇒ page 228 .
– Remove bench seat ⇒ page 304 .
– Remove backrest ⇒ page 305 .
– Remove side panel trim ⇒ page 233 .
All vehicles
– Remove luggage compartment cover side support
⇒ page 241 .
– Remove roof end strip ⇒ page 246 .
– Remove airbag emblem -1- and remove bolt -2- (4 Nm).
Note
When reinstalled, airbag emblem -1- must be renewed.
– Remove nut -3- (1.5 Nm).
– Release trim from stud of nut -3- -arrow A-.
– Release trim from mountings -arrow B- and from door seal
beading.
– Pull trim upwards out of mountings in body -arrow C-.
Golf 2004 ➤ , Golf 2009 ➤
General body repairs, interior - Edition 05.2010
232 Rep. Gr.70 - Trim, insulation
