2.2.2 Installing
– Install in reverse order of removal.
Note
Before installing, check securing clips for damage and renew if
necessary.
2.3 Removing and installing front door trim
on passenger side
2.3.1 Removing
– Switch off ignition.
– Using a removal wedge -3409- , lever upper part of handle
recess -1- out of door handle in door trim.
– Remove bolts -2- and -3- (4 Nm).
– Remove bolt -4- and the three bolts -5- (2 Nm).
– Using removal pliers -3392- , release bottom section of door
trim from mountings.
– Using removal pliers -3392- , release sides of door trim from
mountings.
– Pull door trim upwards vertically out of window slot.
– If vehicle is equipped with a radio system, disconnect wiring
harness from loudspeaker.
– Disconnect wiring harness of door trim from door control unit.
– Detach Bowden cable -6- from interior door handle mecha‐
nism -7-.
– Remove bolt -8- (2 Nm) and lever triangular mirror cover -9-
out of fasteners using wedge -3409- .
– If vehicle is equipped with a radio system, disconnect loud‐
speaker wiring harness from cover.
Golf 2004 ➤ , Golf 2009 ➤
General body repairs, interior - Edition 05.2010
206 Rep. Gr.70 - Trim, insulation
