6.4.2 Installing
– Install in reverse order of removal.
– Switch ignition on.
WARNING
Ensure that nobody is in the vehicle.
– Reconnect vehicle battery ⇒ Rep. Gr. 27 .
6.5 Removing and installing rear wheel
housing crash sensors (4-door)
Note
Removal and installation is described for the right vehicle side.
Follow same instructions for the left side as appropriate.
6.5.1 Removing
WARNING
Observe the general safety regulations when working on air‐
bag, belt tensioner and battery isolator units (pyrotechnic com‐
ponents) ⇒ page 90
– Disconnect vehicle battery ⇒ Rep. Gr. 27 .
– Remove bench seat ⇒ page 304 .
Vehicles ▸06/2005
– Remove side padding (4-door):
♦ With rear side airbags ⇒ page 306
♦ with no rear side airbags ⇒ page 307
– Remove wheel housing trim (4-door) ⇒ page 84
Vehicles with rear side airbag, 06/2005▸
– Remove side padding (4-door):
♦ with rear side airbags ⇒ page 306
– Remove wheel housing trim (4-door) ⇒ page 84
Vehicles without rear side airbag, 06/2005▸
– Remove wheel housing trim, 4-door, without rear side airbag
⇒ page 85 .
– Press connector securing device -1- to rear -arrow- and pull
connector -2- off crash sensor -4-.
– Remove the two bolts -3- (9 Nm).
Golf 2004 ➤ , Golf 2009 ➤
General body repairs, interior - Edition 05.2010
6. Crash sensors 181
