WARNING
Never use components of the repair kit separately.
1 - Front seat cushion padding
2 - Pressure hose
3 - Mat for seat occupied rec‐
ognition
4 - Pressure sensor for seat
occupied recognition -G452-
5 - Seat occupied recognition
control unit -J706-
6 - Wiring harness for front seat
7 - Bracket
❑ White
WARNING
Read and follow the in‐
structions for use on the
packaging of the repair
kit. Faulty installation/
use may cause the sys‐
tem to malfunction.
5.5 Removing components of seat occupied
recognition (vehicles with manually op‐
erated seats)
WARNING
Observe safety precautions when working on seat occupied
recognition ⇒ page 154 .
