1.30.2 Installing
– Install in reverse order of removal.
1.31 Removing and installing (electric) lum‐
bar support
Removal and installation of the lumbar support is described for
the left backrest frame. Removal and installation of the lumbar
support on the right backrest frame is similar.
WARNING
Observe the general safety regulations when working on air‐
bag, belt tensioner and battery isolator units (pyrotechnic com‐
ponents) ⇒ page 90
– Attach seat repair stand -VAS 6136- to engine and gearbox
support -VAS 6095- .
– Remove front seat ⇒ page 260 .
– Secure seat to seat repair stand -VAS 6136- .
– Remove right side trim on seat ⇒ page 276 .
Golf 2004 ➤ , Golf 2009 ➤
General body repairs, interior - Edition 05.2010
1. Front seats 301
