1.18 Removing and installing front seat back‐
rest
Note
Removal and installation is described for the left vehicle side.
Follow same instructions for the right side as appropriate.
1.18.1 Removing
– Attach seat repair stand -VAS 6136- to engine and gearbox
support -VAS 6095- .
– Remove front seat ⇒ page 260 .
– Secure seat to seat repair stand -VAS 6136- .
– Remove right side trim on seat ⇒ page 276 .
Vehicles with manually adjustable seat
– Remove left side trim on seat ⇒ page 263 .
Vehicles with electrically adjustable seat
– Remove left side trim on electrically adjustable seat
⇒ page 267 .
All vehicles
– Detach retaining straps for backrest cover from underside of
seat frame.
– Disconnect wiring harnesses for side airbag and for seat heat‐
ing from seat frame (if part of original equipment).
– Remove two bolts each on left and right -1- and -2- (34.5 Nm).
Note
♦
The bolts are microencapsulated and must be renewed each time they are loosened.
♦
Before new bolts are installed, the threads of the corresponding holes must be cleaned.
– Remove backrest from seat frame.
Golf 2004 ➤ , Golf 2009 ➤
General body repairs, interior - Edition 05.2010
1. Front seats 281
