Wacker Neuson 28Z3 Service Manual

SHB 28Z3 EN – Edition 2.0 * 28z3s510.fm 5-35
Hydraulic system
5.19 Auxiliary hydraulics connections
Notice!
Follow the instructions in the Operator's Manual of the attachment manufacturer
for connecting the auxiliary hydraulics to attachments.
Standard ports:
Fig. 37: Connections for auxiliary hydraulics
Port Stick (left) Stick (right)
T Pressure line
V Pressure line
U Large return line
Fig. 38: Connections for auxiliary hydraulics
V
T
U
