2-16 SHB 28Z3 EN – Edition 2.0 * 28z3s210.fm
Specifications
2.18 Lift capacity table 28Z3 long stick (option) and extra weight (option)
All table indications in kg (lbs.) and horizontal position on firm ground without bucket.
If equipped with a bucket or other attachments, lift capacity or tilt load is reduced by bucket
or attachment dead weight.
Calculation basis: according to ISO 10567
The machine's lift capacity is restricted by the settings of the pressure limiting valves and
the hydraulic system's stabilising features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
3.5 m (11.5 ft) 3.0 m (9.8 ft) 2.5 m (8.2 ft)
A
B
Lowered blade Lowered blade Lowered blade Lowered blade
3.0 m
(9.8 ft)
458*
(1009*)
377
(832)
423*
(933*)
423*
(933*)
2.0 m
(6.6 ft)
447*
(985*)
292
(643)
450*
(993*)
367
(809)
473*
(1044*)
473*
(1044*)
1.0 m
(3.3 ft)
453*
(1000*)
266
(586)
526*
(1161*)
346
(764)
625*
(1378*)
437
(964)
811*
(1788*)
573
(1263)
0.0 m
(0.0 ft)
465*
(1026*)
276
(609)
575*
(1269*)
329
(725)
720*
(1588*)
409
(903)
960*
(2116*)
531
(1171)
-1.0 m
(-3.3 ft)
468*
(1033*)
343
(756)
646*
(1425*)
406
(896)
852*
(1879*)
529
(1166)
Fig. 6: Lift capacity table (model 28Z3)
max. Admissible load on extended stick
A Reach from live ring centre
B Load hook height
* Lift capacity limited by hydraulic system
With the stabiliser blade in driving direction
Without the stabiliser blade, 90° to driving direction
