Wacker Neuson 28Z3 Service Manual

7-6 SHB 28Z3 EN – Edition 2.0 * 28z3s710.fm
Options
7.5 3rd control circuit/PowerTilt ports
Standard ports:
Couplings cannot be coupled under pressure!
Notice!
Follow the instructions in the Operator's Manual of the attachment manufacturer
for connecting the 3rd control circuit to attachments.
Standard ports:
Fig. 3: 3rd control circuit/PowerTilt ports
Port Bushing
Standard Bulkhead coupling 1/2”
Quick coupler option Quick coupler ISO De 12.5 1/2”
Fig. 4: 3rd control circuit/PowerTilt ports
V
U
W
VV
X
Port Stick (left) Stick (right)
V
3rd control circuit/PowerTilt
U
3rd control circuit/PowerTilt
W
Grab
X
Grab
