04/2016
6-16
Phaser 4600/4620/4622 Printer Service Manual
GP 17, GP 18
Revised
6 General Procedures and Information
2. Mounting surface flatness must be within the specified range.
3. The printer must not be tipped or tilted more than 10 mm in either direction.
Figure 2 Tilting Specifications
Dimensions
GP 18 Glossary of Terms, Acronyms and Abbreviations
Where possible unit designations as appear in ISO 1000 (International Organization for Stan-
dardization) and Xerox Standard MN2-905 have been used. All measurements appear in ISO
units followed by any conversion in brackets e.g.; 22.5 mm (0.885 inches)
Refer to Table 1.
Table 1 Print Engine
Dimensions N/ DN/ DT
Width 18.3 in. (46.4 cm)
Depth 20.5 in. (52.1 cm)
Height 16.4 in. (41.9 cm)
Weight 66.0 lbs. (30.2 kg)
Table 1 Glossary
Term Description
AAA Authentication, Authorisation and Accounting
ABS Automatic Background Suppression. ABSolute
ACK Acknowledge
AGC Automatic Gain Control
AHA Advanced Hardware Architecture
AMCV Average Monthly Copy Volume
AMPV Average Monthly Print Volume
AMR Automatic Meter Read
AMS Automatic Magnification Selection
ANSI American National Standards Institute
API Application Programming Interface
APS Auto Paper Selection
ARP Address Resolution Protocol. Converts an IP address to a MAC address.
See RARP.
ASIC Application Specific Integrated Circuit
ASP Authorized Service Provider
ASTM American Standard Test Method
ATPD Across The Process Direction
AZAP Any Zone Any Paper
B Bels (applies to sound power level units)
B (A) Bels (A weighted) (applies to sound power level units)
B (A) I Bels (A weighted) Impulse response (applies to sound power level units)
BABT British Approvals Board for Tele-Communication
BAM Bundes Anstalt fur Materialprufung
BEUI BIOS Extended User Interface
Bluetooth Wireless local area network
BootP Boot Protocol. AN IP protocol for automatically assigning IP addresses.
bps Bits per second
BS Behavior Specification
BT Busy Tone
C Celsius
CAT Customer Admin Tool
CB Certification Bodies
CCA Cenelec Certification Agreement
