ABB PST72 Installation And Commissioning Manual

Functions
Chapter 10
157
1SFC132003M0201
10:53 By-pass doesn't close fault,
type of operation
Path in menu:
Menu/SETTINGS/Functional Settings/Faults/BP Open Op
This parameter makes it possible to select between two
different actions of the softstarter if the by-pass contactor
does not close in a proper way.
Stop-M The motor stops and a manual reset is required
before restart.
Stop-A The motor stops and an automatic reset is
performed when the fault disappears.
10:54 Programmable inputs, In0 and In1
Path in menu:
Menu/SETTINGS/Functional Settings/
Inputs/In0 / In1
The softstarter has two programmable inputs, In0 and In1.
They can be used for different purposes depending on the
selected function, independently of each other.
Caution!
The motor may start unexpectedly if there is a start signal
present when doing any of the actions listed below.
Parameter
text
Default value Setting range Description
BP Open
Op
Stop-M Stop-M, Stop-A Type of opera-
tion if the by-
pass does not
close
Parameter
text
Default value Setting range Description
In0 Reset None, Reset,
Enable, Jog, DOL,
Start2, FB-Dis
Function of pro-
grammable input
In0
In1 Reset None, Reset,
Enable, Jog, DOL,
Start3, FB-Dis
Function of pro-
grammable input
In1
