Settings and configuration
Chapter 7
78
1SFC132003M0201
7:1.1 Overview of all accessible settings
(different menus)
Setting/parameter Top
level
Application
Setting
Basic
Settings
Functional
Settings
Presentation
Settings
All
Settings
Reset all
Settings
Password X
Keypad lock/unlock X
Reset to factory default setting X
Application type X
Setting current X X X X
Overload protection class X X X X
External by-pass X X X X
Start mode Tune Set X X X
Stop mode Tune Set X X X
Start ramp Tune Set X X X
Stop ramp Tune Set X X X
Initial voltage Tune Set X X X
End voltage Tune Set X X X
Step down voltage Tune Set X X X
Current limit Tune Set X X X
Torque limit Tune Set X X X
Kick start X X
Kick start level X X
Kick start time X X
Start ramp range X X
Stop ramp range X X
Tune torque control X X
Overload protection type X X
Overload protection, dual type, start
class
XX
Overload protection, dual type, run
class
XX
Overload protection, type of opera-
tion
XX
Locked rotor protection X X
Locked rotor protection level X X
Locked rotor protection time X X
Locked rotor protection, type of
operation
XX
Underload protection X X
Underload protection level X X
Underload protection time X X
Underload protection, type of opera-
tion
XX
Phase imbalance protection X X
Phase imbalance protection level X X
Phase imbalance protection, type of
operation
XX
High current protection X X
High current protection, type of
operation
XX
Phase reversal protection X X
Phase reversal protection, type of
operation
XX
PTC protection X X
PTC protection, type of operation X X
High current warning X X
High current warning level X X
