Human-Machine Interfac
e (HMI)
Chapter 6
73
1SFC132003M0201
6:2.7
Reset Event
s menu
The Reset Event
s menu is entered automatically when a faul
t
has occurred or a protection is
activated. It can also be
entered via the main
menu.
Use naviga
tion keys t
o view if
there are
several ev
ents to
reset.
F
igur
e 27:
Reset Events menu
T
op level
Settings
Local Control
S
tatus Information
Reset Events
Event Log
72
74
Table of Contents
Table of Contents
7
Introduction
10
About the Complete Set of Documentation for a Softstarter
11
About the Installation and Commissioning Manual
11
Intended Audience
11
General
11
Requirements
12
Chapters Included
12
Revision Notes
12
Acronyms and Abbreviations
13
Chapter 1 Introduction
11
Quickstart
16
Description Chapter 3 Description
19
Description
20
Chapter 3 Description
21
Overview
21
Functions
22
Markings and Connections
24
Industrial IT
25
Type Designation
25
Environmental Influence
26
Specifications
26
Technical Data
27
General
27
Semi-Conductor Fuses
27
Softstarter Types
28
Weights
30
UL Information
30
Dimensions
31
Mounting
36
Connection Chapter 5 Connection
41
Connection
42
Chapter 5 Connection
43
Electrical Connection
43
Main Circuit
43
External By-Pass Contactor
45
Protective Earthing
45
Supply Voltage and Control Circuit
47
Supply Voltage, Terminals 1 and 2
47
Earthing, Terminal 3
47
Start and Stop, Terminals 4, 5, 8, 9, 10, 11
48
Programmable Inputs, Terminals 6 and 7
50
Programmable Output Relay K4, Terminals 12, 13 and 14
52
Programmable Output Relay K5, Terminals 15, 16 and 17
52
Programmable Output Relay K6, Terminals 18, 19 and 20
53
PTC Input
53
Analog Output
54
Emergency Closing of Contactor (PSTB370
54
General
43
Connection of Communication Devices (Optional)
56
Fieldbus Communication
56
External Keypad
57
Transferring of Parameters
58
Uploading of Parameters
58
Downloading of Parameters
58
Technical Data
59
Human-Machine Interface (Hmi) Chapter 6 Human-Machine Interface (Hmi)
61
Human-Machine Interface (HMI)
62
Chapter 6 Human-Machine Interface (HMI)
63
Overview
63
Design
64
Application
65
Password
66
Setting Password
66
Wrong Password
66
Locking/Unlocking the Keypad
67
Menu Tree
68
Overview
68
Top Level
69
Settings Menu
69
Local Control Menu
70
Start/Stop the Motor
70
Jog
71
DOL Start
71
Event Log Menu
72
Status Information Menu
72
Reset Events Menu
73
Setting and Configuration Chapter 7 Settings and Configuration
75
Settings and Configuration
76
Chapter 7 Settings and Configuration
77
Settings
77
Overview of All Accessible Settings (Different Menus)
78
Parameter List
81
Description of Menus
85
Top Level
85
Application Setting
87
Basic Settings
90
Functional Settings
92
Start/Stop
92
Torque Control
94
Protections
95
Warnings
101
Faults
102
Inputs
104
Outputs
106
Analog Output
108
Fieldbus
110
Sequence Start
111
Presentation Settings
114
Service Settings
116
All Settings
116
Changed Settings
117
Reset All Settings
117
Operation Mode
118
Fieldbus Communication (Option)
120
Maintenance
124
Function Chapter 10 Functions
127
Chapter 10 Functions
131
Setting Current
131
Start Mode
132
Stop Mode
133
Start Ramp
134
Tune Torque Control
134
Initial Voltage
135
Stop Ramp
135
End Voltage 30
136
Step down Voltage
136
Current Limit
137
Torque Limit
137
Kick Start
138
Kick Start Level
138
Kick Start Time
138
Start Ramp Range
139
Stop Ramp Range
139
Overload Protection Class
140
Overload Protection Type
140
Overload Protection, Dual Type, Run Class
141
Overload Protection, Dual Type, Start Class
141
Overload Protection, Type of Operation
142
Locked Rotor Protection
143
Locked Rotor Protection Level
143
Locked Rotor Protection Time
144
Locked Rotor Protection, Type of Operation
144
Underload Protection
145
Underload Protection Level
145
Underload Protection Time
146
Underload Protection, Type of Operation
146
Phase Imbalance Protection
147
Phase Imbalance Protection Level
147
High Current Protection
148
Phase Imbalance Protection, Type of Operation
148
High Current Protection, Type of Operation
149
Phase Reversal Protection
149
Phase Reversal Protection, Type of Operation
150
PTC Protection
150
External By-Pass
151
PTC Protection, Type of Operation
151
High Current Warning
152
High Current Warning Level
152
Low Current Warning
152
Low Current Warning Level
153
Overload Warning
153
Overload Warning Level
153
Fieldbus Fault, Type of Operation
154
Phase Loss Fault, Type of Operation
154
Thyristor (SCR) Overload Warning
154
Frequency Fault, Type of Operation
155
Heat Sink Over-Temperature Fault, Type of Operation
155
Thyristor Short Circuit Fault, Type of Operation
156
Type of Operation
156
Programmable Inputs, In0 and In1
157
Type of Operation
157
Programmable Output Relays, K4, K5 and K6
159
Analog Output
161
Programmable Software Output V7
161
Analog Output, Reference
162
Analog Output, Type of Value
162
Analog Output, Range Max
163
Fieldbus Control
164
Fieldbus Type
165
Fieldbus Address
166
Fieldbus Auto Disable
166
Sequence Start, Number of Sequences
167
Start Ramp, First Sequence
167
Current Limit, First Sequence
168
Initial Voltage, First Sequence
168
Setting Current, First Sequence
168
Current Limit, Second Sequence
169
Initial Voltage, Second Sequence
169
Start Ramp, Second Sequence
169
Initial Voltage, Third Sequence
170
Setting Current, Second Sequence
170
Start Ramp, Third Sequence
170
Current Limit, Third Sequence
171
Setting Current, Third Sequence
171
Language
172
LCD Automatic Switch-Off
172
Password
173
Date Type
173
Year
174
Month
174
Day
174
Hour
175
Minutes
175
Dual Current Limit Time
176
Dual Current Limit Level
176
Trouble Shooting Chapter 11 Trouble Shooting
177
Trouble Shooting
177
Trouble Shooting
178
Chapter 11 Trouble Shooting
179
General
179
Overview of Indications
179
General Problems and Faults
180
Fault Indication
181
Start up Faults
181
Protection Indication
185
