ABB PST72 Installation And Commissioning Manual

Human-Machine Interface (HMI)
Chapter 6
69
1SFC132003M0201
6:2.2 Top level
Top Level contains general softstarter information, and the
menus can be reached from here.
The selections are presented one by one on the top row. Use
navigation keys to present all selections.
Press Select to enter a function.
Press Back to return to previous state.
6:2.3 Settings menu
The settings menu is used to set up the softstarter with
parameters for the current application.
The types of settings are presented one by one on the top
line.
Use navigation keys to present all selections.
Top level
F
igure 19: Top level
Settings
Local Control
Event Log
Status Information
Reset Events
Function Description
Settings Set up softstarter parameters.
Local Control Control the softstarter.
Event Log Present the Event Log, faults, pro-
tections, warnings.
Status Information Present various information.
Reset Events Reset of events.
Figure 20: Settings menu
Settings
Local Control
Event Log
Status Information
Reset Events
Top level
Application setting
Basic settings
Functional settings
Presentation settings
Service settings
All settings
Changed settings
Reset all settings
Operation Mode
Function Description
Application Setting Use predefined parameters for
type of applications.
Basic settings The basic and most used settings.
Functional settings Settings are arranged after func-
tions.
Presentation settings Language, date, time etc.
Service settings Settings for use during service
and repair.
All settings A list with all possible settings.
Changed settings A list with all changed settings.
Reset all settings Reset all settings to factory default
settings.
Operation Mode Test mode for the softstarter.
