6:2.5 Event Log menu
The Event Log menu is used to check the event log in the
softstarter. When entering this menu the 21 latest events in
the log are presented, in chronological order with the latest
event as No. 1, the second latest as No. 2 etc.
The events are presented with “type of event”, date and time.
Use navigation keys to view all entries in the event log.
6:2.6 Status Information menu
The Status information menu is used to present various
information.
The information is presented one by one on the top row.
Use navigation keys to present all information.
Displayed phase currents L1, L2, and L3 are the delta
currents if unit is connected inside delta, otherwise line
current.
F
igure 25: Event Log menu
Top level
Settings
Local Control
Event Log
Status Information
Reset Events
Figure 26:Event Log menu
Top level
Settings
Local Control
Event Log
Status Information
Reset Events
Display text Function
Frequency Measured frequency.
Phase seq. Phase sequence indication.
Connection Type of connection, In Line/Inside Delta.
Phase L1 Phase current L1.
Phase L2 Phase current L2.
Phase L3 Phase current L3.
Line Voltage The incoming line voltage [U].
cosPhi Power factor.
P kW Active power [kW].
P hp Active power [hp]
Q kVAr Reactive power [kVAr]
S kVA Apparent power [kVA]
Run Time Total run time of the motor.
No. Of Starts Counted number of starts.
SW Ver. CU Software version CU.
SW Ver. FU Software version FU.
SW Ver. KP
1
Software version Ext. keypad.
DB version Database version
MAC Address Internal addressing.
LV Board No Serial No of the LV PCB.
1) only if connected
