ABB PST72 Installation And Commissioning Manual

Human-Machine Interface (HMI)
Chapter 6
65
1SFC132003M0201
The functionality of the keypad is illustrated by the following
example:
Changing the Rated motor current (Setting I
e
).
1. You will find the setting as well as a short explanation and
the path to it in Chapter 10 “Functions” .
Path in menu:
Menu/SETTINGS/Functional Settings/
Start/Stop /Setting Ie
2. The top level of the softstarter start menu looks as in fig-
ure 3. Press the left selection key to enter the menu. The
display now appears as in figure 4.
3. Press the left selection key to select SETTINGS. The dis-
play appears as in figure 5.
4. Press the lower navigation key until the display appears
as in figure 6.
5. Press the left selection key to select Functional settings.
Press the left selection key to select Start/Stop, figure 7.
6. Press the left selection key to Change the Setting Ie set-
ting, figure 8.
The display now appears as in figure 9.
7. Use the navigation keys to set the rated current. If you
want to quit, you select Cancel, using the right selection
key. Or else, you store the new setting by selecting Store
with the left selection key. The display should now appear
as in figure 10.
8. Press the right selection key four times to return to top
level.
U= 0% I=0.0A
Menu
F
igure 3: Top level
SETTINGS
Select Back
F
igure 4: SETTINGS menu
Application Setting
Select Back
F
igure 5: Application Setting menu
F
igure 6: Functional settings menu
Functional Setting
Select Back
Start/Stop
Select Back
F
igure 7: Start/Stop menu
Setting Ie 100A
Change Back
F
igure 8: Setting Ie menu
Setting Ie 100A
Store Cancel
F
igure 9: Setting Ie, changing menu
Setting Ie 99.5A
Change Back
F
igure 10: Setting Ie menu, changed setting
