Functions
Chapter 10
161
1SFC132003M0201
10:56 Programmable software output V7
Path in menu:
Menu/SETTINGS/Functional Settings/
Outputs/SW Outp V7
If the softstarter is used with fieldbus communication, a fourth
output is available. This is a software output only and the
signal can be taken only through the fieldbus interface.
(See 50 “Programmable output relays, K4, K5, and K6” for
further explanations.
10:57 Analog output
Path in menu:
Menu/SETTINGS/Functional Settings/
Analog Output /Analog Out
With this parameter it is possible to enable the analog output.
The softstarter has one analog output. The terminals used for
the analog output are also used for the PTC protection
though, so only one of these functions can be used at any
given time.
When sequence start is used, the analog output is only active
for the last started motor.
Parameter
text
Default value Setting range Description
SW Outp
V7
Event Run, TOR, Event Function of pro-
grammable soft-
ware output V7.
Parameter
text
Default value Setting range Description
Analog Out No Yes, No Enable analog
output
