6:2.4.2 Jog
Enter the Jog menu, figure 23.
Select Jog. The motor will start and accelerate to rated speed
according to the set parameters as long as the Jog command
is activated.
The motor stops immediately as soon as the command is
released.
6:2.4.3 DOL start
(PSTB370...1050 only)
Start from the softstarter
If required, the motor can be started DOL (Direct On Line)
with the integrated by-pass contactor.
Select the DOL start menu, figure 24.
Select DOL start to close the integrated by-pass contactor.
Select Stop to open the contactor.
This menu is available only if the parameter Setting I
e
is
equal or lower than the AC-3 rating of the by-pass contactor.
Warning!
The rated motor current must never exceed the AC-3 rating
of the integrated by-pass contactor. See Chapter 3
“Description” for details.
F
igure 23:Jog menu
Top level
Settings
Local Control
Event Log
Status Information
Reset Events
Start/Stop
Jog
DOL Start
F
igure 24: DOL start menu
Top level
Settings
Local Control
Event Log
Status Information
Reset Events
Start/Stop
Jog
DOL Start
