Enova DGX DXLink™ Fiber Boards
123
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Auto-setup
To configure TXs and RXs using traditional NetLinx binding (requires disabling auto-setup), see the Hardware Reference Manual –
DXLink Fiber Transmitters and Receivers.
Need to Know for Auto-setup
□ Endpoints must be set to DHCP Mode (default)
□ Endpoints must use NDP Master connection mode (default)
□ Endpoints must not be currently bound (traditional NetLinx binding) to a Master
□ Endpoint DIP switch setting for Toggle #3 (network connectivity) is ignored while in auto-setup mode
□ Auto-setup is not available for DXLink Fiber hardware in Unidirectional Mode
Disabling Auto-setup Mode
Auto-setup can be disabled for DXLink endpoints by using the System Configuration interface (see page 178) or DGX_SHELL
commands (see below).
IMPORTANT: The DGX_SHELL command to disable auto-setup mode does not persist over a power cycle. If your installation requires
disabling auto-setup through endpoint power cycles, we suggest using the System Configuration interface for this setting.
To disable auto-setup mode using DGX_SHELL commands:
1. Open a terminal emulation program.
2. At the prompt (DGX_SHELL>), type the command to disable auto-setup:
(To determine the BCPUx variable, see page 245.)
Disable all ports on an input or output board –
set BCPUx_auto_setup_disabled=1,2,3,4
Disable port #2 on an input or output board –
set BCPUx_auto_setup_disabled=2
Disable all DXLink boards in the system (including DXLink Twisted Pair) –
set BCPU_auto_setup_disabled=1,2,3,4
3. The endpoint detects the change and reboots with auto-setup disabled.
4. Use traditional NetLinx binding to configure DXLink TXs/RXs.
Enabling Auto-setup Mode
Auto-setup is enabled by default. If disabled, auto-setup can be enabled for DXLink Fiber endpoints by using either the System
Configuration interface (see page 178) or DGX_SHELL commands (see below).
To enable auto-setup mode using DGX_SHELL commands:
1. Open a terminal emulation program.
2. At the prompt (DGX_SHELL>), type the command to disable auto-setup:
(To determine the BCPUx variable, see page 245.)
Enable all ports on an input or output board –
set BCPUx_auto_setup_disabled=,,,
Enable port #2 on an input or output board –
set BCPUx_auto_setup_disabled=1,3,4
Enable all DXLink boards in the system (including DXLink Twisted Pair) –
set BCPU_auto_setup_disabled=,,,
3. The endpoint(s) detects the change and reboots with auto-setup enabled.
Telnet Access to Endpoints in Auto-setup Mode
Endpoints in auto-setup mode are accessible through the ICS LAN port on the Switcher’s CPU. Control is established through a
Telnet session with appropriate Telnet commands for the DXLink Fiber TX/RX (see the Hardware Reference Manual – DXLink Fiber
Transmitters and Receivers at www.amx.com).
CAUTION: The ICS LAN port acts as a DHCP server (private LAN) and the LAN 100/1000 port acts as a DHCP client (public LAN)
with each port on a separate network. In order to avoid a Network Loop, do not connect any device on one network to any branch on
the other network.
IMPORTANT: If auto-setup is being used, Telnet is the only way to access some of the network settings. Also note that some network
settings will disable the auto-setup feature (reference the section “Need to Know for Auto-setup” on page 123).
To access DXLink endpoints via Telnet session:
1. Connect a PC to the ICS LAN port on the left side of the Switcher’s CPU.
2. Open NetLinx Studio.
3. In the OnLine Tree, listen for the 198.18.0.1 device (internal Master IP) and establish a connection.
4. Right-click the endpoint and select TELNET Window/Launch TELNET Window via NetLinx Studio.
NOTE: For additional information on DXLink Fiber units, see the “Hardware Reference Manual – DXLink Fiber Transmitters and
Receivers.”
