Enova DGX HDMI Boards
65
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Enova DGX 4K HDMI Boards – Specifications
This section applies to 4K HDMI Input Board FG1061-540. Specifications for HDMI Input Board (FG1058-540) and HDMI Output
Board (FG1058-550) begin on page 63.
4K HDMI Specifications
Compatible Formats HDMI, HDCP, DVI
Signal Type Support • HDMI
• DVI-D (single link with HDMI cable adapter)
• DisplayPort ++ (Input only, with HDMI cable adapter)
Video Data Rate (max.) 8.91 Gbps (max)
Video Pixel Clock (max.) 297 MHz
Progressive Resolution Support 480p up to 4096x2160p,60 Hz*
*Y/Cb/Cr 4:2:0 & 4K RX Scaler in Bypass
NOTE: See full list of supported formats on page 66.
Interlaced Resolution Support 480i, 576i, 1080i
NOTE: If input is interlaced, all scaled outputs will deinterlace video to a progressive
resolution format. If in scaler Bypass mode interlaced input will pass through unaltered.
Resolution Support 3840x2160p@24/25/30 Hz
4096x2160p@24/25/30 Hz
3840x2160p@60 Hz, 4:2:0*
4096x2160p@60 Hz, 4:2:0*
* Supported by DX-RX-4K when in Bypass Scaling mode.
HDMI Cable Requirement HDMI High Speed Cable, Category 2, Required
Input Equalization Yes, adaptive to 21 ft. (7 m)*
*Cable distance support dependent on cable quality and signal format.
Input Re-clocking (CDR) Yes
Deep Color Support 24-bit, 30-bit, 36-bit
30-bit and 36-bit are only supported when the HDMI Output Board or DXLink RX Scaler is in Bypass
mode and format is 1080p60 or less.
Color Space Support RGB 4:4:4
YCbCr 4:4:4, 4:2:2, and 4:2:0
• Input signal support for YCbCr 4:4:4 and 4:2:2, output color-space is converted to RGB 4:4:4
• 4:2:0 only supported at 2160p 50/60 Hz with 4K RX Scaler in Bypass
3D Format Support • Frame Packing 1080p up to 24 Hz
• Frame Packing 720p up to 50/60 Hz
• Frame Packing 1080i up to 50/60 Hz
• Top-Bottom 1080p up to 24 Hz
• Top-Bottom 720p up to 50/60 Hz
• Side-by-Side Half 1080i up to 50/60 Hz
NOTE: The Scaler on corresponding output board or RX must be set to Bypass mode.
Audio Format Support Dolby TrueHD, Dolby Digital, DTS-HD Master Audio, DTS, 2 CH through 8 CH L-PCM
• Dolby Digital and DTS support up to 48 kHz, 5.1 channels
Audio Resolution 16 bit to 24 bit
Audio Sample Rate 32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
Audio Switching Board Support • Supports break-away audio switching of 2 CH L-PCM for all channels
• Supports downmix from one input channel of Dolby True-HD, Dolby Digital, DTS-HD, DTS, or 2 to
8 channel L-PCM
DDC/EDID Support • EDID provided by Enova DGX Digital Media Switcher
• EDID is user re-programmable
HDCP Support Yes, full matrix HDCP 1.4 support (includes any input to any or all outputs)
• Key Management System
• AMX HDCP InstaGate Pro® Technology
• Key support up to 16 devices per output, independent of source device
CEC Support None
Input Propagation Delay 2 μs
Output +5 V DDC Pin N/A
Connectors 4 HDMI Type A female ports
