Product Overview and General Specifications
29
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Enova DGX 1600 – General Specifications
General Specifications
Parameter Value
Approvals UL 60950-1, CSA 60950-1, IEC 60950-1, CE EN 60950-1, CE EN 55022 Class A,
CE EN 55024, FCC CFR Title 47 Part 15 Subpart B Class A, ICES-003 Class A, RoHS,
WEEE
AC Power per Supply 100-240 +/-10% VAC single phase, 50/60 Hz
Power Capacity (max.) 977 Watts (110 VAC and 230 VAC)
Power Consumption (max.) 953 Watts, fully loaded DXLink Power enclosure with redundancy
Power Consumption (typical) 365 Watts, fully loaded HDMI enclosure with redundancy
Thermal Dissipation Full Capacity (max.) 3334 BTU/hr.
Thermal Dissipation (max.) 3251 BTU/hr, fully loaded DXLink Power enclosure with redundancy
Thermal Dissipation (typical) 1245 BTU/hr, fully loaded HDMI enclosure with redundancy
Power Factor Correction (PFC) Supported, complies with EN60555-2 and EN61000-3-2
Operational Temperature 32° F to 104° F (0° C to 40° C)
Storage Temperature -22° F to 158° F (-30° C to 70° C)
Operational Humidity 5% to 85% RH (non-condensing)
Storage Humidity 0 to 90% RH (non-condensing)
MTBF 627,105 hrs
Dimensions 15 in. (38.1 cm) depth; 16 in. (40.64 cm) depth with extractors
19 in. (48.26 cm) width including integral rack mounting ears
6.84 in. (17.37 cm) height (4 RU)
Weight Approximately 55 lb. (24.95 kg) per loaded enclosure
Shipping Weight Approximately 65 lb. (29.5 kg) per loaded enclosure
Per Channel Aggregate Data Rate (max.) 12.8 Gbps
Noise Level <52.5 dBA @ 1 m (typical @ 25° C)
Airflow Forced air (inlet on side; exhaust on side)
Compatible DXLink™ Twisted Pair Transmitters and
Receivers
• DXLink Multi-Format Transmitter Modules
• DXLink Multi-Format Wallplate Transmitters
• DXLink Multi-Format Decor Style Wallplate Transmitter (US)
• DXLink HDMI Receiver Modules
Compatible DXLink™ Twisted Pair 4K Transmitters
and Receivers
• DXLink 4K HDMI Decor Style Wallplate Transmitters (US)
• DXLink HDMI 4K Receiver Modules
Compatible DXLink™ Fiber Transmitters and
Receivers
• DXLink Multi-Format MM Fiber TX, Duplex/Simplex
• DXLink Multi-Format SM Fiber TX, Duplex/Simplex
• DXLink HDMI MM Fiber RX, Duplex/Simplex
• DXLink HDMI SM Fiber RX, Duplex/Simplex
Compatible Solecis Digital Switchers • Solecis 4x1 HDMI Digital Switcher with DXLink Output
• Solecis 5x1 Multi-Format Digital Switcher with DXLink Output
• Solecis 8x1 HDMI Digital Switcher with DXLink Output
Compatible Solecis 4K Digital Switchers • Solecis 4x1 4K HDMI Digital Switcher with DXLink Output
• Solecis 5x1 4K Multi-Format Digital Switcher with DXLink Output
