Product Overview and General Specifications
32
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Enova DGX – NetLinx and Control Specifications
* Cascaded architecture actual throughput dependent on loading.
Enova DGX 6400: Worst case per port throughput is 7 Mbps. Best case is 100 Mbps when used with 64 DXLink Transmitters
and 64 DXLink Receivers.
Enova DGX 3200: Worst case per port throughput is 10 Mbps. Best case is 100 Mbps when used with 32 DXLink
Transmitters and 32 DXLink Receivers.
Enova DGX 1600: Worst case per port throughput is 10 Mbps. Best case is 100 Mbps when used with 16 DXLink
Transmitters and 16 DXLink Receivers.
Enova DGX 800: Worst case per port throughput is 10 Mbps. Best case is 100 Mbps when used with 8 DXLink Transmitters
and 8 DXLink Receivers.
For individual board information and specifications, see the specific board chapter in this manual.
HDMI Input and Output Boards – page 62
DVI Input and Output Boards – page 74
DXLink Twisted Pair Input and Output Boards – page 82
DXLink Twisted Pair 4K Input and Output Boards – page 97
DXLink Fiber Input and Output Boards – page 109
Dante Audio Switching (expansion) Boards - page 128
Audio Switching (expansion) Boards – page 142
Audio Insert/Extract (expansion) Board – page 154
NetLinx and Control Specifications
Integrated Controller
LAN 100/1000 (Ethernet) Port RJ-45 connector
• NetLinx on-board Master is an NX Class Controller
• TCP/IP uplink port (LAN 10/100/1000)
• Supports up to 64-port unmanaged 10/100 Ethernet Switch*
• Static IP or DHCP/DNS, SSL, Auto-negotiating, Auto MDI/MDI-X Crossover
• Supports IPv4 and IPv6 networks
• Supports HTTP, HTTPS, Telnet, FTP, TCP/IP, UDP/IP, CIP, SMTP
• Built-in Web server
• Includes support for DXLink™ devices
ICS LAN Port RJ-45 connector
• Auto-setup and connection for control of endpoint devices
Processor 1600 MIPS
Memory • SDRAM 512 MB
• NVRAM 1 MB
• Flash 8 GB
Program Port (USB) USB Mini-AB connector
• Used for NetLinx Studio control
ID Pushbutton ID Pushbutton to set IP mode or revert to default configuration and firmware
Configuration DIP Switch 2-position
• PRD Mode Setup
Enclosure Control
Control Port (Serial) DB-9 connector
• Bidirectional RS-232
• Baud rates of 9600, 19200, 38400, 57600, 115200 (default)
Control Port (USB) USB Mini-B connector
AxLink Port 4-position 3.5 mm screw terminal
• Provides data and power to external AxLink control devices
• 3A Max Load
USB (HID) Keyboard & Mouse Use the Enova DGX Digital Media Switcher in conjunction with DXLink Transmitters
and Receivers (twisted pair and/or fiber), connect a DXLink TX to a PC and a DXLink
RX to a keyboard and mouse, the system then emulates commands from the receiver
back to the PC. The Solecis SDX-510M functions as a DXLink Transmitter in this
scenario.
For a list of HID devices which have been tested and found to be working well with
the latest firmware, please view the document, “DXLink HID Keyboard and Mouse
Supported Devices” at
www.amx.com on the product page for your DXLink Fiber
Receiver or DXLink Twisted Pair Receiver.
