Enova DGX DVI Boards
75
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
InstaGate Pro
®
and SmartScale
®
DVI Boards meet HDCP Standards and support InstaGate Pro Technology.
For information on HDCP functionality for DVI Boards, see “HDCP Support on Enova DGX Switchers” on page 70.
DVI Input Boards provide EDID emulation support with plug-and-play information provided by the Enova DGX Switcher.
DVI Output Boards feature SmartScale Technology which automatically responds to the display’s preferred EDID
information and scales the video to the best resolution and video settings for that display without manual setup.
DVI Boards are HDCP 1.4 compatible and feature InstaGate Pro Technology* for low-latency switching of HDCP protected
content and support computer video up to 1920x1200 and HDTV up to 1080p. The EDID of the input will need to be
changed to allow for HDMI formatted signals, so that the source device can send out that signal style. If the EDID on the
input board has been properly modified and the downstream sink has proper declarations in its EDID, the DVI connectors
also support embedded audio, both linear PCM (stereo audio) and non-linear PCM (Dolby Digital, Dolby TrueHD, DTS, etc.).
* InstaGate Pro Technology eliminates HDCP latency and interruptions on all displays in a system. (These conditions are typically
experienced when HDCP authenticates HDMI source and destination devices.) Key limitations on source devices are also eliminated
by allowing them to see only a single sink key from the DVI Input Board’s input connection. With InstaGate Pro Technology, when a
source requires HDCP encrypted content, the inputs and compliant downstream devices are automatically authenticated – it just
works.
NOTE: Enova DGX Boards do not support CEC.
Audio Support on DVI Boards
When DVI Boards are set up to support HDMI signals, the audio information in the HDMI Board chapter applies (see page 62).
Enova DGX DVI Boards – Specifications
Applies to input board FG1058-600 and output board FG1058-610.
Digital Video – DVI Specifications
Parameter Value
Compatible Formats DVI, HDMI, HDCP
Signal Type DVI-D (single link with HDMI cable adapter)
HDMI
DisplayPort ++ (Input only, with HDMI cable adapter)
HDMI Mode Support DVI Boards can be run in HDMI mode with an EDID update which will provide full HDMI functionality
and board specifications
Video Data Rate (max.) 4.95 Gbps / 6.75 Gbps
(6.75 only supported when the HDMI Output Board Scaler or DXLink RX Scaler is in Bypass mode
and format is 1080p60 or less with deep color)
Video Pixel Clock (max.) 165 MHz / 225 MHz
(225 MHz only supported when the HDMI Output Board Scaler or DXLink RX Scaler is in Bypass
mode and format is 1080p60 or less with deep color)
Progressive Resolution Support 480p up to 1920x1200 @ 60 Hz
(If the signal is interlaced, all scaled outputs will deinterlace video to a progressive resolution
format. If in scaler Bypass mode, interlaced input will pass through unaltered.)
Interlaced Resolution Support 480i, 576i,1080i
(If the signal is interlaced, all scaled outputs will deinterlace video to a progressive resolution
format. If in scaler Bypass mode, interlaced input will pass through unaltered.)
2K Resolution Support 2048x1024@47Hz; 2048x1080@60Hz; 2048x1152@60Hz; 2048x1536@24Hz
• 2K formats are only compatible with DVI, HDMI, and DXLink Fiber Input/Output Boards and
require the output scaler or RX Scaler to be set in Bypass mode
Input Equalization Yes, adaptive up to 100 ft. (30 m) at 225 MHz
• Cable distance support dependent on cable type and signal format.
Input Re-clocking (CDR) Yes
Output Re-clocking Yes
Output Scaling SmartScale, Manual Configuration, Bypass
SmartScale Output Resolution
Support
All resolutions between 480p and 1920x1200@60Hz via automatic SmartScale query of the
display’s preferred EDID Detailed Timing Definition
Deep Color Support 24-bit, 30-bit, 36-bit
(30-bit, 36-bit only supported when the HDMI Output Board Scaler or DXLink RX Scaler is in
Bypass mode and format is 1080p60 or less)
Color Space Support • RGB 4:4:4
• YCbCr 4:4:4 and 4:2:2
(Input signal support for YCbCr 4:4:4 and 4:2:2, output color-space is converted to RGB 4:4:4)
