Integrated Master – NetLinx® Programming
186
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
NetLinx Channels and Levels
NetLinx Channels
NetLinx Channels
Channel Type Usage Ports Description
Output Audio (Switched Audio Only)
24 CMD Pulse, ON/OFF All A/V & ASB Outputs Volume Up
25 CMD Pulse, ON/OFF All A/V & ASB Outputs Volume Down
26 CMD Pulse All A/V & ASB Outputs Volume Mute Toggle
199 CMD, FDBK ON/OFF All A/V & ASB Outputs Volume Mute
164 CMD Pulse, ON/OFF All A/V & ASB Outputs Balance Ramp Up
165 CMD Pulse, ON/OFF All A/V & ASB Outputs Balance Ramp Down
DXLink TX VGA Input Video
83 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In Phase Up
84 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In Phase Down
132 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In V Shift Up
133 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In V Shift Down
134 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In H Shift Up
135 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In H Shift Down
Output Video
210 CMD, FDBK ON/OFF All A/V Outputs Video Mute
213 CMD, FDBK ON/OFF All A/V Outputs Video Freeze
234 CMD, FDBK ON/OFF All A/V Outputs On-Screen Display (OSD)
System Alarm Status
216 FDBK N/A Responds on 5002:1:0 Fan Alarm Status
217 FDBK N/A Responds on 5002:1:0 Temperature Alarm Status
218 FDBK N/A Responds on 5002:1:0 Power Alarm Status
