Product Overview and General Specifications
35
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Enova DGX 100 Series and Enova DGX 8/16/32/64 Differences
The Enova DGX 100 Series has incorporated a number of technological advancements which resulted in changes that may be of
interest to users of previous Enova DGX products. In order to assist these users, we have included the table below which captures
some of the main system differences (highlighted cells represent changes that may affect programming code in existing systems).
Enova DGX 100 Series and Enova DGX 8/16/32/64 Differences
Enova DGX 8/16/32/64 Series Enova DGX 100 Series
NetLinx Programming and Switcher Control
Switcher Control (NetLinx ICSP)
CHANGE
Can be sent to Port 2 or 3
CIxOyT (default A/V switch)
CL<level>IxOyT (where <level>=0,1)
Must be sent to Port 1
(see commands on page 188)
Switcher Control (NetLinx ICSP)
STATUS
Can be sent to Port 2 or 3
SIxT
SOyT
Must be sent to Port 1
(see commands on page 188)
Switcher Control (NetLinx ICSP)
DISCONNECT
Can be sent to Port 2 or 3
DIxT
DOyT
Must be sent to Port 1
• uses 0 to disconnect - outputs ONLY
(see commands on page 188)
Serial (COM1) port
USB (COM2) port
9600 baud, defaults to bcs
(USB uses APBridge driver)
15200 baud, defaults to DGX_SHELL>
(see section on page 240)
Switcher Control (Serial) Standard bcs commands Standard bcs commands
Switcher Control (Web Control
page) http://Master_IP_address
Master Configuration Manager
Device 5002 / IP Control / XBar Controller
System Configuration interface
Switcher / Switching or Configuration pages
Switcher Control
(Telnet Interface)
BCS Tunnel (telnet to Master on port 15000)
Supports basic bcs commands only
Telnet interface supports DGX_SHELL (default)
and bcs commands.
(see section on page 243)
Local Presets Local presets configurable via XNConnect Does not support Local Presets
File system Case insensitive Case sensitive (more secure)
DEFINE_PROGRAM execution Standard NetLinx execution Possible timing differences (depends on program
variables)
PRD mode Settable via DIP switch on CPU board inside
enclosure
Settable via DIP switch on CPU faceplate
Device Binding, Addressing, and Network Options
Binding devices to the DGX
Master
Traditional binding only (defaults to NDP) • Defaults to Auto-setup automatic binding of
each device on the Private LAN (page 25)
• Traditional binding supported if Auto-setup is
disabled in the System Configuration interface
Status page
Device Addressing Device name given via NDP or specified by user • In Auto-setup, endpoints are given an address
per I/O channel (see page 25)
• With Auto-setup disabled, traditional device
address rules apply
Network addressing • The DGX Master and each endpoint device
consumes an IP address on the Public LAN
• Endpoint ICSLAN ports pass Public IP
• In Auto-setup, the DGX Master consumes a
single Public IP address but all endpoints are
given predefined Private LAN addresses
(see page 25)
• With Auto-setup disabled, each endpoint gets
a Public IP address
• Endpoint ICS LAN ports ONLY pass Public IP
• The Master and switcher always have Private
LAN addresses:
• DGX Master: 198.18.0.1
• DGX Switcher: 198.18.128.1
WARNING: The master Public IP must NEVER
use a 198.18.x.x subnet. Doing so will prevent
the 5002 device from coming online.
Telnet to Endpoints Telnet to any point on the Public LAN as long as
the PC is on the Public LAN
In Auto-setup, can ONLY telnet to endpoints
when connected directly to the endpoint’s
ICS LAN port so that your PC receives an IP
address on the Private LAN
Internet Protocol Versions and
Network Security
IPv4 only • IPv4 and IPv6
• Wired 802.1x security for protected networks
