AMX DGX3200-ENC User Manual

Enova DGX Dante™ Audio Switching Boards
131
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
NOTE: Only 2 channel L-PCM audio is supported by the Dante Audio Switching Output Board unless downmixing is employed. All
other audio formats will be muted before the output connector.
Audio DSP Adjustments Per Output (embedded video and auxiliary outputs)
Audio Output DSP • Independent EQ, Volume and Balance control per output
• 10-band parametric EQ with variable center frequency, filter type and Q per band
o Center Frequency: 20 Hz to 20 kHz
o EQ Gain: -12 to +12 dB
o Q: 0.1 to 20
o Filter Types: Bell, Base Shelving, Treble Shelving, Low Pass, High Pass, Band Pass,
Band Stop
• Audio Output Volume adjustments with minimum and maximum limiter settings per
output
• Audio Output Sync Delay: 0 to 200 ms (Default 32ms)
• Balance Control: 20 steps each, left and right
Audio Mixing Stereo to Mono conversion per output
Test Tone Generator Single selection of test tone type available on all outputs simultaneously. Individually
enabled/disabled per output - 60 Hz, 250 Hz, 400 Hz, 1 kHz, 3,Hz, 5 kHz, 10 kHz, Pink
Noise, White Noise
Dante Audio
Dante Audio Inputs • 8 Stereo Pair Inputs (16 Dante Receiver Channels)
• Supported Incoming Sample Frequencies 44.1, 48, 88.2, 96, 176.4, 192 kHz at 16, 20
and 24-bit (Default set to 48kHz and 24-bit)
• Clocking supports Dante Network Source Generation or Sink Locking
• (2) RJ-45 1-Gbps Ports supporting Daisy Chain (Dante Switched Mode) or Redundant
Modes (Daisy Chain set as default)
• Latency supports 250 μsec, 500 μsec, 1 msec, 2 msec and 5 msec (1 msec default)
• Device Identification supported through Dante's Identify Device (RJ-45 LED indication)
• Dante Brooklyn II module
Dante Audio Outputs • 8 Stereo Pair Outputs (16 Dante Transmitter Channels)
• Outgoing Sample Frequency of 48 kHz at 24-bit
• Clocking supports Dante Network Source Generation or Sink Locking
• (2) RJ-45 1-Gbps Ports supporting Daisy Chain (Dante Switched Mode) or Redundant
Modes (Daisy Chain set as default)
• Latency supports 250 μsec, 500 μsec, 1 msec, 2 msec, and 5 msec (1 msec default)
• Device Identification supported through Dante's Identify Device (RJ-45 LED indication)
• Dante Brooklyn II module
Downmix
Downmix Input Downmix input fed from selectable embedded audio input from any Enova DGX Input
Board. Downmixed audio switchable to all embedded/Dante audio outputs.
Downmix input format support Dolby TrueHD, Dolby Digital, DTS-HD Master Audio, DTS, 2 Ch through 8 Ch L-PCM
Enova DGX Dante Audio Switching Board Specifications
