Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Appendix C – DGX_SHELL Commands
* In the Enova DGX 6400, the numbering for input boards starts at the top left of the enclosure going down half way, continuing at
the top right of the enclosure going down; the output boards repeat the same pattern in the lower portion of the enclosure (for
illustration, see page 18).
Product to Board Slot Correspondence
Product Board Orientation Board Slot Number Connector Numbers
Enova DGX 6400 Horizontal
1 Inputs 1-4
2 Inputs 5-8
3 Inputs 9-12
4 Inputs 13-16
5 Inputs 17-20
6 Inputs 21-24
7 Inputs 25-28
8 Inputs 29-32
9 Inputs 33-36
10 Inputs 37-40
11 Inputs 41-44
12 Inputs 45-48
13 Inputs 49-52
14 Inputs 53-56
15 Inputs 57-60
16 Inputs 61-64
17 Outputs 1-4
18 Outputs 5-8
19 Outputs 9-12
20 Outputs 13-16
21 Outputs 17-20
22 Outputs 21-24
23 Outputs 25-28
24 Outputs 29-32
25 Outputs 33-36
26 Outputs 37-40
27 Outputs 41-44
28 Outputs 45-48
29 Outputs 49-52
30 Outputs 53-56
31 Outputs 57-60
32 Outputs 61-64
