Version 7.2 125 Mediant 1000B Gateway & E-SBC
User's Manual 12. Network
12 Network
This section describes network-related configuration.
12.1 Building and Viewing your Network Topology
The Network view lets you easily build and view your voice network topology entities,
including IP network interfaces, Ethernet Devices (VLANs), Ethernet Groups, and physical
Ethernet ports. The Topology view graphically displays these entities and the associations
between them, giving you a better understanding of your network topology and
configuration. You can use the Network view as an alternative to configuring the entities in
their respective Web pages or you can use it in combination.
To access the Network view:
Click the Network View home icon (Setup menu > IP Network tab > Network
View).
The areas of the Network view is shown in the example below and described in the
subsequent table.
Note: The below figure is used only as an example; your device may show different
Ethernet Groups and Ethernet ports.
Figure 12-1: Network View (Example)
