User's Manual 752 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
An example of a configured Dial Plan (# 6) in the Dial Plan file is shown below:
[ PLAN6 ]
200,0,10.33.8.52 ; called prefix 200 is routed to
10.33.8.52
201,0,10.33.8.52
300,0,itsp.com ; called prefix 300 is routed to itsp.com
2. Convert the file to a loadable file and then load it to the device (see ''Creating a Dial
Plan File'' on page 746).
3. Assign the Dial Plan index to the required routing rule:
• SBC Calls: In the SBC IP-to-IP Routing table, do the following:
a. Set the 'Destination Type' field to Dial Plan.
b. In the 'Destination Address' field, enter the required Dial Plan index, where
"0" denotes [PLAN1] in the Dial Plan file, "1" denotes [PLAN2], and so on.
• Tel-to-IP Calls (Gateway application): In the Tel-to-IP Routing table, do the
following:
a. In the 'Destination Address' field, enter the required Dial Plan index using the
following syntax:
DialPlan<index>
Where "DialPlan0" denotes [PLAN1] in the Dial Plan file, "DialPlan1" denotes
[PLAN2], and so on.
Note: The "DialPlan" string is case-sensitive.
43.1.7.5 Modifying ISDN-to-IP Calling Party Number
You can use the Dial Plan file to change the Calling Party Number value (source number)
of the incoming ISDN call when sending to IP.
Note: The feature is applicable only to digital interfaces.
Use the following syntax in the Dial Plan file:
<ISDN Calling Party Number>,0,<new calling number>
<ISDN Calling Party Number>: Calling party number (or its prefix) received in the
ISDN call SETUP message. The source number can also be a range, using the syntax
[x-y] in the Dial Plan file. This number is used as the display name in the From header
of the outgoing INVITE.
The second number must always be set to "0".
<new calling number>: String of up to 12 characters containing the mapped number
that is used as the URI user part in the From and Contact headers of the outgoing
INVITE.
Below shows an example of such a configuration in the Dial Plan file:
[ PLAN1 ]
; specific received number changed to 04343434181.
0567811181,0,04343434181
