Version 7.2 157 Mediant 1000B Gateway & E-SBC
User's Manual 12. Network
2. Click New; the following dialog box appears:
Figure 12-14: Internal DNS Table - Add Dialog Box
3. Configure a DNS rule according to the parameters described in the table below.
4. Click Apply.
Table 12-19: Internal DNS Table Parameter Description
Parameter Description
Index Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Domain Name
domain-name
[Dns2Ip_DomainName]
Defines the host name to be translated.
The valid value is a string of up to 31 characters.
First IP Address
first-ip-address
[Dns2Ip_FirstIpAddress]
Defines the first IP address (in dotted-decimal format notation) to
which the host name is translated. The IP address can be
configured as an IPv4 and/or IPv6 address.
Second IP Address
second-ip-address
[Dns2Ip_SecondIpAddress]
Defines the second IP address (in dotted-decimal format notation)
to which the host name is translated.
Third IP Address
third-ip-address
[Dns2Ip_ThirdIpAddress]
Defines the third IP address (in dotted-decimal format notation) to
which the host name is translated.
12.10.2 Configuring the Internal SRV Table
The Internal SRV table resolves host names to DNS A-Records. Three different A-Records
can be assigned to each host name, where each A-Record contains the host name,
priority, weight, and port.
