User's Manual 234 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
15.3.4 Configuring LDAP Servers
The LDAP Servers table lets you configure up to four LDAP servers. The table defines the
address and connectivity settings of the LDAP server. The LDAP server can be configured
for SIP-related queries (e.g., routing and manipulation) or LDAP-based management user
login authentication and authorization (username-password).
The following procedure describes how to configure an LDAP server through the Web
interface. You can also configure it through ini file (LdapConfiguration) or CLI (configure
system > ldap ldap-configuration).
Note: When you configure an LDAP server, you need to assign it an LDAP Server
Group. Therefore, before you can configure an LDAP server in the table, you must
first configure at least one LDAP Server Group in the LDAP Server Groups table (see
''Configuring LDAP Server Groups'' on page 232).
 To configure an LDAP server:
1. Open the LDAP Servers table (Setup menu > IP Network tab > RADIUS & LDAP
folder > LDAP Servers).
2. Click New; the following dialog box appears:
Figure 15-19: LDAP Servers Table - Add Dialog Box
3. Configure an LDAP server according to the parameters described in the table below.
4. Click Apply.
Table 15-8: LDAP Servers Table Parameter Descriptions
Parameter Description
General
Index
[LdapConfiguration_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
LDAP Servers Group Assigns the
LDAP server to an LDAP Server Group, configured in
the LDAP Server Groups table (see ''Configuring LDAP Server
