User's Manual 170 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
2. Click New; the following dialog box appears:
Figure 13-5: IDS Policies Table - Add Dialog Box
3. Configure an IDS Policy name according to the parameters described in the table
below.
4. Click Apply.
Table 13-3: IDS Policies Table Parameter Descriptions
Parameter Description
Index
policy
[IDSPolicy_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
rule
[IDSPolicy_Name]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 40 characters.
Description
description
[IDSPolicy_Description]
Defines a brief description for the IDS Policy.
The valid value is a string of up to 100 characters.
5. In the IDS Policies table, select the required IDS Policy row, and then click the IDS
Rule link located below the table; the IDS Rule table opens.
