D9412GV4/D7412GV4 v2.03 | Installation and System Reference Guide | 3.0 Overview
.
Bosch Security Systems, Inc. | 7/16 | F01U265457-09 12
Table 2: Control Panel Comparisons
Features D9412GV4 D7412GV4
Access Control Yes - 8 doors Yes - 2 doors
Number of Arm/Disarm Users 999 399
Number of Cards/Tokens 999 399
Number of Passcode-Protected Custom Functions 16 4
Number of Points 246 75
Number of Off-board Relays 128 64
Number of Areas 32 8
Number of SDI2 Keypads 16 16
Number of SDI Keypads
1
16 16
Number of Phone Lines Supported
2
2 2
Number of B208 Octo-input Modules 24 7
3
Number of B308 Octo-output Modules
12 6
4
Number of B420 Ethernet Communication Module
2
5
2
5
Number of B426 Ethernet Communication Module
2
5
2
5
Number of B450 Plug-in Communicator Interface
6
2
5
2
5
Number of B520 Auxiliary Power Supply Module
8 8
Number of RADION receiver SD (B810)
7
1 1
Number of B820 SDI2 Inovonics Interface Modules
1 1
1
The maximum number of D1260 keypads on the SDI bus is eight.
2
On a two phone line system, a D928 Dual Phone Line Switcher is required in order to transmit over a second phone line.
3
For the D7412GV4, only 5 inputs are available on the Octo-input at address 7.
4
For the D7412GV4, only 4 outputs are available on the Octo-output at address 6.
5
The maximum number of communication devices to be used on the control panel is two on the SDI bus, and two on the SDI2 bus. If
automation is enabled on the SDI bus, an additional module can be added. Of the two devices that can be used on the SDI2 bus both can be
used for reporting / RPS communications or one can be used for reporting / RPS communications and the other can be used for automation.
6
Must have a B44x Plug-in Cellular Communicator inserted into the B450 in order for the B450 to be operational.
7
Refer to the device-specific installation instructions for each RADION wireless device.
3.1.1 Parts List
The control panels are shipped assembled
from the factory with the following parts:
Literature Pack
7000/9000 Series Point Chart Label
(P/N: 79-06660-000)
Assembly
PC board
Faceplate shield
Mounting skirt
One #6 x 3/4-in screw
3.1.2 Products Available by Separate Order
Order the following products separately to
complete a basic eight-point installation.
B450 Plug-in Communicator Interface
B440 Conettix Plug-in Cellular
Communicator (using 3G)
B441 Conettix Plug-in Cellular
Communicator (using CDMA)
B442 Conettix Plug-in Cellular
Communicator (using GPRS)
The D1260 and D1260B Keypads must
have firmware version 1.04 or higher
for use with the D9412GV4/D7412GV4
Control Panels.
