D9412GV4/D7412GV4 v2.03 | Installation and System Reference Guide | 17.0 Approved Applications
.
Bosch Security Systems, Inc. | 7/16 | F01U265457-09 88
17.0 Approved Applications
The UL System Chart (Table 38 on page 149)
references the components that are evaluated
and listed by UL for compatibility with the
D9412GV4/D7412GV4 v2.03 control panel.
These components meet the basic system
requirements for the applicable standard.
The System Wiring Diagrams, (refer to
Appendix A: System Wiring Diagrams on pages
99 to 104) show the relationship between the
control panel and the accessory components
referred to in Figure 40 on page 159.
17.1 Optional Compatible
Equipment
UL Listed components not requiring evaluation
for electrical compatibility can be used in many
applications when installed according to the
manufacturer’s instructions.
17.2 Burglary Applications
UL Listed burglary alarm sensors not requiring
evaluation for electrical compatibility can be
used in burglary applications. In some cases, a
UL Listed interface module must be used with
the sensors. Consult the individual component
specification and installation documents to
determine suitability.
Test Weekly: UL Standard 1023
requires a weekly test for residential
burglary applications.
17.3 Bank Safe and Vault
Applications
The UL Listed Model 5110 Bell and Model
4001-42 External Line Balancer (both made by
Rothenbuhler) must be used for the bell and
balanced line module in bank safe and vault
applications. Modify the D8108A Attack-
Resistant Enclosure to meet UL Standard 681.
17.3.1 Control Panel Enclosure
Requirements
UL Standard 681 for Installation and
Classification of Mercantile and Bank Burglary
Alarm Systems requires foil lining or equivalent
protection of the control unit enclosure. The
D8108A Attack-Resistant Enclosure does not
have a foil lining, but acceptable protection is
provided by mounting electronic vibration
sensors inside the enclosure. Refer to
Figure 13 on page 39.
Do not use proximity alarms
(capacitance) to protect the control
panel enclosure.
Install the same electronic vibration sensors in
the D8108A that are used to protect the safe
or vault. Mount the Sentrol 5402, Potter EVD-S,
or Arrowhead S-3810 electronic vibration
detection (EVD) system inside the D8108A to
meet the UL 681 requirements.
Mount the EVD sensor directly inside the metal
cabinet of the D8108A as shown in Figure 13
on page 44.
Do not install the EVD sensor within
6.4 mm (0.25 in.) of the components
or traces of the printed circuit
assembly.
Install and test the EVD sensor according to
the manufacturer’s instructions.
17.3.2 Battery Connections
Using a D122 Dual Battery Harness, connect
two 12 V batteries in the control panel
enclosure. Refer to Figure 13 Figure 13 for
battery placement information.
Use a separate D8108A for the 12 V batteries.
When using a D122L Dual Battery Harness,
wire the batteries in parallel and connect the
harness to Terminals 4 and 5 of the control
panel.
Auxiliary power, limited to 300 mA for
72 h, as required by for standby
mercantile bank safe, and vault
applications.
17.3.3 Bell Requirements
Use the following Rothenbuhler bell and
balanced line modules with the control panel:
