D9412GV4/D7412GV4 v2.03 | Installation and System Reference Guide | 17.6 Programming Options
.
Bosch Security Systems, Inc. | 7/16 | F01U265457-09 99
ZRS-MCC-FW 24 VDC, Selectable 15/30/75/95 cd, White
ZRS-MCCH-FR 24 VDC, Selectable 115/177 cd, Red
ZRS-MCCH-FW 24 VDC, Selectable 115/177 cd, White
17.5 Enclosures
Bosch Security Systems offers three optional enclosures for the control panel. Sections 17.5.1 D8103
Enclosure, 17.5.2 D8108A Enclosure, and 17.5.3 D8109 Red Fire Enclosure describe the three
options.
17.5.1 D8103 Enclosure
The D8103 is suitable for residential fire and burglary installations and commercial burglary
applications that do not require attack resistance or the approval by Factory Mutual (FM) or New York
City – Materials and Equipment Acceptance (NYC-MEA). Refer to Table 38 on page 149 for acceptable
applications.
17.5.2 D8108A Enclosure
The D8108A is attack resistant and intended primarily for UL commercial burglar alarm and mercantile
safe and vault applications requiring a local bell. This enclosure can be used in any burglar or fire
alarm application where the D8109 Enclosure is suitable.
The D8108A, with some modification, can be used for bank safe and vault applications as described in
Section 17.3 Bank Safe and Vault Applications on page 88. UL lists the D8108A for all commercial fire
alarm applications. It is approved by FM, CSFM, and the NYC-MEA.
17.5.3 D8109 Red Fire Enclosure
Generally, the D8109 is used for fire alarm applications. UL lists the D8109 for all commercial fire
alarm applications. It is approved by FM, CSFM, and the NYC-MEA.
All references to NFPA and related
requirements are based on
compliance with the NFPA 72
National Fire Alarm Code. Because
installation specifications are
generally based on a specific
edition of a standard that was
legally adopted by the authority
having jurisdiction (AHJ), consult
with the appropriate AHJ for
confirmation.
17.6 Programming Options
17.6.1 UL 864
This section identifies the programming requirements you must make in order to comply with UL 864
Commercial Fire applications.
