D9412GV4/D7412GV4 v2.03 | Installation and System Reference Guide | 17.0 Approved Applications
.
Bosch Security Systems, Inc. | 7/16 | F01U265457-09 92
17.4.5 Other Devices
Use a D130 Relay Module, D8129 OctoRelay, or
Switched Aux (Terminal 8) to provide reset
capability to other initiating devices such as:
D125B Powered Loop Interface Module
(2-wire smoke detector module)
D129 Dual Class A Initiation Circuit
Module (4-wire smoke detector)
D9127T/U POPITs
On-board points
Install devices according to the manufacturer’s
instructions. Refer to Off-Board Outputs on
page 60 for more information.
For battery calculations, refer to Table 41 on
page 152 and Section 22.0 NFPA 72 Fire Alarm
Applications on page 155.
Test Weekly: Perform a Fire Test
weekly. Both the AC power and
battery are tested according to UL
864 (D9412GV4/D7412GV4).
