D9412GV4/D7412GV4 v2.03 | Installation and System Reference Guide | 3.0 Overview
.
Bosch Security Systems, Inc. | 7/16 | F01U265457-09 19
3.3.13 Ground Fault Detection Added
Feature
When Ground Fault Detect is enabled (S4
closed), Points can be used for non-powered
fire-initiating devices such as heat detectors,
four-wire smoke detectors, and pull stations. A
D125B Powered Loop Interface or a D129 Dual
Class A Interface Module is not required when
connecting the non-powered fire-initiating
devices to Points.
3.3.14 Conettix Functions
The D6600/D6100i/D6100IPV6 Conettix
System supports data network
communications. Conettix allows the
D6600/D6100i/D6100IPV6 Receiver/Gateway
devices to connect to various network
technologies including Ethernet, UDP/IP, and
Ethernet cellular data.
Connecting to a data network is possible using
the COM4 or COM1 connection from the
D6600/D6100i Receiver to the D6680 Network
Adapter. Control panels can send reports
through telephone lines, Ethernet, UDP/IP, or
GPRS networks to the
D6600/D6100i/D6100IPV6 receiver to the
central station. Once events are received, they
can then be issued to automation software or a
network printer through a local area network
(LAN) or wide area network (WAN).
Sending events to the central station over a
LAN or WAN requires a network interface
module (NIM), such as the B420, B426, or
B450.
3.3.15 Programming
Use the RPS, or the Keypad Installer menu, to
program the control panels. Refer to the
Control Panels (D9412GV4/D7412GV4 v2.03)
Program Entry Guide (P/N: F01U265459) for
programming options.
3.3.16 Dual Authentication
The D9412GV4 and D7412GV4 control panels
can be configured to require two forms of
identification before processing certain system
commands. This feature requires a door
controller and a keypad to be installed within
proximity to each other for user convenience.
Dual Authentication requires a
D9210C door controller module or
B942/B942W touch screen keypad
even though the configured operation
may not be access.
A standard system user has authority to use
Dual Authentication if they have a passcode, a
door credential (token or card), and
appropriate command authority permissions
assigned in the door and keypads assigned
area. When enabled at a keypad, only the
following Passcode Functions require access
credentials with passcode entry, Arm / Disarm,
Cycle Door (Grant Access), Cycle Relay, and
Auto Re-arm. Refer to the Control Panels
(D9412GV4/D7412GV4 v2.03) Program Entry
Guide (P/N: F01U265459)and D9210C
Installation and Operation Guide (P/N:
F01U215232) for details on installation,
configuration and operation of this feature.
3.3.17 Other Features
The D9412GV4/D7412GV4 v2.03 Control
Panels have many programmable features.
Some of the features are listed below.
Complete details on all features are in the
Control Panels (D9412GV4/D7412GV4 v2.03)
Program Entry Guide (P/N: F01U265459):
 Supervision of AC (primary power),
battery (secondary power), Zonex, SDI
and SDI2 buses, central processing unit
(CPU), and two telephone lines
 Automatic System Test Reports
 Remote access for programming,
diagnostics, and log uploads using the
remote programming software (RPS)
 Fire alarm verification
 Programmable alarm outputs
 Programmable relay outputs
 Opening and closing windows
 SKEDs (scheduled events)
 Limited local programming

Bosch D9412GV4 Specifications

General

Power Supply	12 VDC
Type	Control Panel
Model	D9412GV4
Manufacturer	Bosch
Operating Temperature	0°C to +49°C (+32°F to +120°F)
Compatible with	Conettix IP, GSM, GPRS, and POTS communicators
